TableLegsOnline
Low Profile 6" Diameter Rectangle Table Base
(No reviews yet)
Write a Review
- SKU:
- 187XL
- MPN:
- 187XL
Description
The 187XL Square or Rectangle pedestal base is an excellent choice to maximize space under a table while giving you superior support with its 6" column. These low profile discs almost make the base disappear into the floor while still maintaining the stability and mobility needed in a freestanding table. Our standard style has no levelers and it sits flat on the floor almost undetected by your feet. Levelers are offered as an option, and position the base about 1" off the floor.
- Height: 27-3/4"; 40-1/4"
- Construction: Bolted Assembly and Welded Construction
- Finish: Black (standard)
- Other finishes: Require additional 2-1/2 to 3 week lead time for nine (9) powder coat finishes
- Column diameter: 6"
- Mounting plate: Fabricated Steel 4 gauge x 12" x 12"; requires (12) #12-14 screws
- Leveler foot allows additional 3/4" upward height adjustment for uneven floors (Additional Option / Not Standard)
- 330 lbs. vertical load rating per base
- Pricing is per base
| Base Spread | Weight | Recommended Max. Top Size |
| 18" x 28" | 55 lbs. | 36" x 60" |
| 23" x 23" | 60 lbs. | 48" Round / Square |
| 24 x 28" | 66 lbs. | 42" x 60" |
Additional Information
Color/Finsh : |
Black (standard), Black wrinkle, Champagne, Dark tone, Gray (Medium), Inner tone light, Light brown (Sand), Light tone, Medium tone, Silver, Sky White, White (Soft) |
Column Tubing : |
13 gauge wall |
Construction : |
Welded Construction and Bolted Assembly |
Cutting : |
Can be custom cut at factory |
Diameter : |
6" |
Function/Application : |
Table Bases |
Height : |
27-3/4", 40-3/4" |
Material : |
Metal / Steel |
Mounting-Style : |
12" Square |
Base Spread : |
18" x 28", 23-3/4" Square, 24" x 28" |
Height Adjustment : |
3/4" |
Load Rating : |
330 lbs (150kg) static vertical load |
Packing Units: |
Single |
Shape : |
Round |
